90 Degree Male Coax MCX Connector Cable Sf085

Get high-quality 90 Degree Male Coax MCX Connector Cable Sf085 directly from the factory. Durable and reliable cables for your needs. Fast shipping available.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Application
  • Company Profile
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
RHT-617-0100
VSWR
Straight
Brand
Renhotec
Impedence
50 Ohm
Orientation
Angled/90 Degree
Plating
Gold Plating
Contact
Brass
Factory Direct Sale
Yes
OEM
Weclome
Product Name
90 Degree Male Coax MCX Connector Cable Sf085
Transport Package
100PCS in a Tray, Then 1000PCS Packed in a Case
Specification
ROHS compliant; SGS
Trademark
RENHOTEC
Origin
Dongguan, Guangdong, China
Production Capacity
80000 Pieces Per Month

Product Description


90 Degree Male Coax MCX Connector Cable Sf085

Welcome to Renhotec Group Ltd! Our Slogan is Make Connection Easier...
Product Description

90 Degree Male Coax MCX Connector Cable Sf085
MCX/MMCX (Micro-Miniature Coaxial) connector are developed in Europe during the 1980s to 1990s, broadband capability of DC to 6 GHz and secure, fast and easy snap-on/snap-off coupling. Conforms to the European CECC 22000 specification.With small size, less weight, compact structure and easy fit, they are widely used in small sized communication equipment.

Features:-Broadband performance with low reflection
-High-quality solution at a low cost
-Quick connect/disconnect snap-on mating reduces installation time
-Conforms to European CECC 22000 specifications
-Available in straight and right angle plugs and printed circuit board connectors

90 Degree Male Coax MCX Connector Cable Sf085



Impedance
50Ω / 75Ω
Cable Type
RG 178, RG 179, RG 316, RG 316/U, RG 405
Body Material
Beryllium Copper / Brass
Body Finish
Bright Tin / Gold / Nickel / Matte Tin / White Bronze
Contact Material
Beryllium Copper / Brass /Phosphor Bronze
Insulator Material
Delrin / PTFE
Frequency Range
DC - 6 GHz
Voltage Rating
≥170 Volts RMS Continuous
Dielectric Withstanding Voltage
1000 VRMS Max
Insulation Resistance
500 MΩ  Min
Center Contact Resistance
5 Min
Outer Contact Resistance
1 Min
VSWR
≤1.15(DC to 4 GHz) , ≤1.40(4 to 6 GHz)
Temperature Range
−65°C to +165°C
Mating Cycles
500 Min
Application

90 Degree Male Coax MCX Connector Cable Sf085

WLAN,Global Positioning System (GPS),PC/LAN,Automotive,Base Station,Head End Equipment,Radios,Wireless/Network Antenna,Instrumentation,Telecommunications

Company Profile

90 Degree Male Coax MCX Connector Cable Sf085
Renhotec Hardware Electronics Co., Ltd.
RENHOTEC is a full-service leading global supplier of a wide variety of standard and custom RF coaxial connectors, cable assemblies and unique solutions for today's cutting edge applications.
RENHOTEC is fully committed to meeting the needs of our customers, we offer a wide range of RF connector interface types and are able to produce custom products for specific applications.
Our team is always focused on designing, developing and taking pride in custom innovative solutions to meet our customers' needs.

- Acquired ISO9001ISO14001QC080000 and TS16949 certification.
- All items are in line with EU ROHS and REACH environmental requirements.
- Markets supported include automotive, medical, instrumentation, telecom and wireless etc.


Our Advantages
90 Degree Male Coax MCX Connector Cable Sf085
Customized Design
Professional engineer team help you with drawing design and provide you suggestions based on your special electrical and environmental performance requirements.
Technology Improvement
Establish and optimize the process of the production line. Continuous improvement to make sure the targeted quality and yield achieved and maintain
90 Degree Male Coax MCX Connector Cable Sf085
90 Degree Male Coax MCX Connector Cable Sf085
Quality Inspection Center
With professional inspection center to test the electrical, mechanical and environmental performance and ensure the high quality.



FAQ

Q :How can I get a sample to check your quality?
A : Free sample is available.

Q :What is your term of delivery?
A : Usually, we use EXW. As well, FOB, CIF and DDP are all available. Others can be netotiatable.


Q :When can I get the price?
A : All the quotaitons can be handled within 6-12 hours.


Q: Could you accept custom products?
A: Yes, Any custom design can be offered.


Q :What about the lead time for the mass production?
A :Honestly, it depends on the order quantity and the season you place the order. Normally, it is about 20-25 days for qty around 50K.
