China Cheap Side Mounted Float Level Switch for Petrochemical

Find reliable China cheap side mounted float level switch for petrochemical at our factory. High quality and direct from manufacturer. Order now!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
Overview

Basic Info.

Model NO.
UQK
Production Process
Float Ball
Feature
Level Alarm
Material
Stainless Steel
IP Rating
IP65
Certification
ISO
Customized
Customized
Function2
High Level Alarm
Function3
Low Level Alarm
Contact Way
Spdt
Wet Material
SUS304/SS316
Anti Explosion
Yes
Customizable
Yes
Aplication
Water Piquid Oil Petrochemical
Transport Package
Wooden Case or Carton
Specification
side mounted
Trademark
U-ideal
Origin
Tianjin, China
HS Code
8536500000
Production Capacity
3000PCS/Month

Packaging & Delivery

Package Size
20.00cm * 27.00cm * 40.00cm
Package Gross Weight
10.000kg

Product Description

Product Description

UQK Float Level Controller

 UQK magnetic float liquid level swith consist of reed and magnetic float ball, which is based on the floating principle that utilizes magnetic float ball to make the relevant reed close or open according to the height changng of the liquid level, thus controlling and measuring the liquid level.


China Cheap Side Mounted Float Level Switch for Petrochemical
The UQK series is a side mount magnetic float level switch product line consisting of rugged, industrial grade float level switches using the principles of buoyancy and magnetism to provide high, low and intermediate level detection of fluids with specific gravity ranging from as low as 0.25, thereby ensuring a very wide range of application and use. A change in fluid level can correspondingly cause the float to travel up or down. The UQK series side mounted magnetic float level switch product line incorporates SPDT reed switch or SPDT micro switch output and are available in stainless steel or polypropylene wetted materials. Marine certification and explosion proof versions are available.
China Cheap Side Mounted Float Level Switch Liquid Tank Level Sensor Level Switch Liquid For Petrochemical


1. Robust Construction: The UQK Marine Switch is constructed using high-quality materials that can endure the challenges posed by the marine environment. It is typically made of corrosion-resistant metals and features a durable housing to protect the internal components.


2. Waterproof Design: One of the critical features of the UQK Marine Switch is its waterproof design. It is specifically designed to prevent water ingress, ensuring reliable operation even in wet conditions. This feature helps to prevent electrical failures caused by moisture or water splashes.


3. Saltwater Resistance: Saltwater can be highly corrosive to electrical components. The UQK Marine Switch is built to resist the corrosive effects of saltwater, making it suitable for use in saltwater environments such as oceans and seas.


4. Vibration Resistance: Marine vessels often experience significant vibrations caused by the engine, waves, and rough seas. The UQK Marine Switch is designed to withstand these vibrations, ensuring that it remains securely in place and maintains its functionality.

5. Versatile Switching Functions: The UQK Marine Switch can be used for various switching functions on board a marine vessel. It can be employed to control lighting systems, electrical equipment, pumps, fans, and other devices, providing a reliable means of managing electrical circuits.


Technical Parameter:   Customizable
Model Model type Working pressure Working temperature Float diameter Material
Float Flange connection
UQK-10 Side-mounting basic type 1MPa -30~100ºC Φ41 SUS304 SUS304  Thread
UQK-10T Side-mounting extension type 1MPa -30~250ºC Φ41 SUS304 SUS304 Flange/thread
UQK-20 Side-mounting different type 1MPa -30~100ºC Φ41 SUS304 SUS304 Flange
UQK-20T Side-mounting large type 1MPa -30~200ºC Φ41 SUS304 SUS304 Flange
UQK-21 Side mounting 1MPa -30~200ºC Φ75 SUS304 SUS304 Flange
UQK-30 Z TYPE Side mounting  1MPa -30~100ºC Φ41 SUS304 SUS304 Flange
UQK-41 High temp Side mounting 1MPa -30~350ºC Φ41 SUS304 SUS304 Flange
UQK-50 Top mounteing type 1MPa -30~100ºC Φ41 SUS304 SUS304 Flange

Products: customizable
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical
other products:
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical


our company :
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical

packing :
China Cheap Side Mounted Float Level Switch for Petrochemical
China Cheap Side Mounted Float Level Switch for Petrochemical
