Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable

Shop our high-quality coaxial cables including Rg6u, Rg58, Rg59, Rg11, and Kx6 for communication, data, and TV needs. We are a factory direct supplier." Looking for Coaxial Rg6u, Rg58, Rg59, Rg11, or Kx6 cables for your communication, data, or TV needs? Look no further, we are a factory direct supplier offering high-quality products.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
RG58/RG59/RG6/RG11/KX6/RG58+2C/RG59+2C/RG6+2C
Material Shape
Round Wire
Range of Application
LSOH
Certification
ISO9001, CE, RoHS
Brand
Sunmech
Coaxial Cable
CCTV/RG6
PVC Color
White/Black.Orange/Blue/as Request
Transport Package
Wooden Reel/Plastic Reel/Paper Spool
Specification
100M/200M/300M
Trademark
SUNMECH
Origin
China
HS Code
8544200000

Product Description

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
IMPEDANCE:  75Ohm ± 2Ohm
NOMINAL CAPACITANCE:   -51.2 pF/m ± 2 pF/m
VELOCITY RATIO: .87% ± 4%
SCREENING EFFICIENCY:  0-3150MHz > 85dB
STRUCTURAL RETURN LOSS:  -0-1000 MHz > 24dB
                                                     1000-3150 MHIz > 23dB .

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable


Terms:

1.OEM is welcomed

2.ISO/CE/ETL/ROHS/UL/SONCAP and other certifications are available

3.Competitive price and high quality offered.

4. Best service for you!

RG6U DIFFERENT SHIELD

 Procuct Construction STANDARD SHIELD TRI-SHIELD QUAD-SHIELD

CONDUCTOR
MATERIAL BC/CCS BC/CCS BC/CCS
Nom.Dia. 18AWG 18AWG 18AWG

DIELECTRIC
MATERIAL Foam PE Foam PE Foam PE
Nom.Dia. 4.57mm 4.57mm 4.57mm

SHIELD
MATERIAL Al Foil+Al Braiding Al Foil+Al Braiding+Al Foil (Al Foil+Al Braiding)*2
COVERAGE 40%-95% 40%-95% 40%-60%


JACKET
MATERIAL PVC/PE PVC/PE PVC/PE
Nom.Thick. 0.80mm 0.80mm 0.86mm
Nom.Dia. 6.91mm 7.06mm 7.62mm

MESSENGER
MATERIAL Galvanized steel wire
Nom.Dia. 1.30mm 1.30mm 1.30mm



Nominal Impedance(ohm)

75±3

Nominal Velocity of propagation(%)

85

Nominal Capacitance(pf/m)

50

Spark Test(VAC)

3000

SRL(dB)

20

20













Attenuation

[68°F(20ºC)]

Frequency(MHz)

Maximum(dB/100ft)

Maximum(dB/100m)

5

0.58

1.9

55

1.6

5.25

187

2.85

9.35

300

3.55

11.64

450

4.4

14.43

600

5.1

16.73

750

5.65

18.54

865

6.1

20.01

1000

6.55

21.49


Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable



Products Construction
Item RG58 RG59 RG6 RG7 RG11
Inner Conductor(mm) 0.5 0.81 1.02 1.29 1.63
Dielectric(mm) 2.9 3.66 4.57 5.72 7.11
Shisld(mm) 3.15 3.84 5.4 5.9 7.29
Jacket(mm)Standard-Shield 5.1 6.1 6.9 8.1 10.16
Jacket(mm)Tri-Shield 5.2 6.2 7.06 8.2 10.16
Jacket(mm)Quad-Shield 5.74 6.73 7.54 8.64 10.34

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable




Coaxial Cable Packing :
1). Coil With Carton
100M/Coil, 6 Coil/Carton
200M/Coil, 300M/Coil, 2 Coil/Carton
Other Length: 20Yard/Coil. 30Yard Coil, 60YardCoil, 100Yard/Coil.
2). Reel With Pallet or Not
100MPaper Reel
100MPlastic Reel, 200M Plastic Reel, 305M/Plastic.
305M/Wooden Reel, 500M/Wooden Reel
3). Reel In Box, With Pallet
500ft Reel in Box.
1000ftReel in Box.
Color Box and OEM Package available.
20" Contaner Fu1l Load: 350-420km.
40" Container Full Load: 650-780km.

Communication satellite cable TV antenna 18awg satellite RG6U rg6 coaxial cables

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable


Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable

Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable
Coaxial Rg6u CATV Cable 75ohm Rg58 Rg59 with Power Rg11 Kx6 Communication Data Coaxial TV Cable

                                                                                                            F A Q

1, Who are we?
We were founded at the year of 2006 in Zhejiang China. We sell our products to Europe(28.00%), Middle East(26.00%), Africa(25.00%), Asia(12.00%), South America(5.00%), North America(3.00%), Oceania(1.00%). There are about 51-100 workers in our factory.

2, How can we guarantee quality?
Always a pre-productsion samples before mass production
Always final inspection before shipment

3, What can you buy from us?
Coaxial cable, Network cable, Patch cord cable, Telephone cable, Alarm cable, Electric wire, Speaker wire, Microphone wire, ABC cable, Fiber Optic cable, Communication cable, Data cable, Cable tie, Electrical tape, Non-woven products, and some related Tools and Accessories

4, Why should you buy from us not from other suppliers?
Professional Technician Team
Professional & Hard-working Employee
Professional, Hornest, Warm-heart Service
We Guide & Sell you not the best, not the Cheapest but the Most suitable goods for your market. Once business start, After-sale service forever.

5, What's the MOQ:
Usually, the MOQ is 30km, but every inquiry will be considered individually.

6, What service can we provide?
Accepted Delivery Term: FOB, CFR,CIF
Accepted Payment Currency: USD, EU, GBP, CNY
Accepted Payment Type: T/T, L/C, D/P, Western Union
