Basic Info.
Model NO.
TPW-DC-XX-10-DF
HS Code
8517709000
Production Capacity
500PCS/ Day
Packaging & Delivery
Package Size
8.00cm * 5.00cm * 3.00cm
Package Gross Weight
1.000kg
Product Description
| Product Description |
| Model NO. | TPW-DC-XX-10-DF |
| Place of Origin | China |
| Frequency Range | 10-100MHz |
| Insertion Loss | ≤0.2dB |
| VSWR | ≤1.2 |
| coupling dgree | 50±1dB |
| Flatness of coupling | ≤±0.5dB |
| Directivity | ≥18dB |
| Connector | 7/16DIN Female, SMA-K |
| Features & Benefits |
·Guaranteed Parameters Compliance
·Wideband Frequency Band Coverage
·Low Insertion Loss
·Low VSWR
·Indoor & Outdoor Using IP65
·Available with Type N, 7/16DIN, 4.3/10 Connectors
| Recommended Products |
Rotary Variable Step Attenuator Duplexer Diplexer 4.3-10 Female for Radio Reapter 3dB Hybrid Coupler Combiner N Female
| About us |
Hefei Topwave Telecom Co.,Ltd, is a worldwide leading provider of comprehensive RF passive equipment and high-performance wireless infrastructure solutions focused on innovation and differentiation at the edge of wireless telecommunication networks.
Topwave Telecom established in 2007, located in Hefei National High-tech Zone. With the decades of development, we have our own R&D center and manufacturer center.We are OEM and ODM service provider and network operators to improve performance and reduce operating expenses via comprehensive set of products and solutions. Topwave has more than 10 years experience to export goods to all over the world, the RF passive devices like power splitter, coupler, filter, multiband combiner etc, which widely used for DAS, IBS, BTS and BDA.
Topwave persist to provide excellent products and service for every client as always. Our mission is to make the world connected, make the world small, and make the world smart. Topwave Telecom, your trusted strategic business partner, your RF expert in telecommunication.
| Main Products |
| Application |
| Packing Details |
| Testing Equipment |
| FAQ |
Q: Can I get smaples for validation test?
A: Let's talk, some samples are free but shipping charge should be on your account.
Q: What is your MOQ?
A: We don't have MOQ limit.
Q: What is your payment terms?
A: We accept Western Union, T/T, Paypal and so on.
Q: What is your delievry time?
A: Normally around 2 weeks, TBD for massive quantity or customized products.
Q: Why should you buy from us not from other suppliers?
World Factory For RF Products;
Automatic Production Lines;
Professional R&D Team.
