Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel

Steel Bar Couplers Rebar Splicing System from our factory save cost and offer easy operation. Find the best rebar coupler factorysteel here.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Company Profile
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Model NO.
12-40mm
Technics
Forged
Application
Oil Pipe
Customized
Customized
Certification
CQC, CCC, PSE, TUV, VDE, SGS
Warranty
2 Years
Type
Standard Rebar Couplers
Standard
Threaded Splicing Coupler
Building
Modern
Production Process
Upset and Threading
Transport Package
Carton
Specification
25mm
Trademark
CPDL
Origin
China
HS Code
73181900
Production Capacity
5000000PCS/Month

Product Description

Product Description

Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel

Standard rebar couplers made by raw material 45# carbon steel with competitive price and divided into standard couplers, positional rebar couplers, and transition rebar couplers.

Name:

Thread Rebar Couplers Standard Type

Used for Rebar:

HRB400/Grade 65/ and so on with rebar yield strength same as 500Mpa   or lower than that.

Raw Material:

S45C -yield strength 420Mpa, Tensile strength: 600-650MPa

Size:

16mm/18mm/20mm/25mm/28mm/32mm/36mm/40mm

Packing:

By bags and pallets packing, or wooden case packing as required (25KG   smaller packing, 1700KG per pallet)

Sample:

Free existing samples for checking dimension and quality

Production time:

15-40 days based on different quantity after receive the prepayment

Shipping Port:

Xingang,Tianjin Port,  Shanghai   Port, China.

Payment Terms:

TT / LC

Certificate:

ISO/ CE



SIZE (mm)

Out Diameter (mm)

Length (mm)

Pitch (mm)

N.W    (KG)

PACKING IN ONE BAG  (NOS)

1 BAG WEIGHT (KG)

Approvals/ Certificate

16

24

42

2.5

0.092

250

23.00

CE / ISO

18

27

45

2.5

0.136

200

27.20

CE / ISO

20

30

50

2.5

0.159

132

20.98

CE / ISO

22

33

54

2.5

0.21

121

25.41

CE / ISO

25

38

62

3.0

0.34

80

27.20

CE / ISO

28

42

68

3.0

0.46

56

25.76

CE / ISO

32

48

76

3.0

0.633

42

26.58

CE / ISO

36

53

84

3.0

0.905

27

24.43

CE / ISO

40

59

95

3.0

1.16

25

29.00

CE / ISO



1. Standard rebar couplers Introduction

Standard rebar coupler belongs to Rolling technology, it is a parallel-thread mechanical splicing system used for the 16mm to 40mm reinforcing bars mechanical connections. This system is first peeling the rebar rib and then doing thread by cold rolling, this technology can meet with China standard of JGJ107-2010, USA standard of ACI318, UK standard of BS8110, VN standard of TCVN8163, and other international standards. The couplers can be divided into standard couplers with all right-hand thread, and also positional rebar coupler with one side left-hand thread another size right-hand thread, also it has transition couplers which two sides have different diameters. Also, this coupler has a competitive price over super couplers and is suitable for little lower rebar grades such as HRB400 or HRB500 rebar, it has full sizes from 16mm to 40mm.

2.45# steel carbon steel rebar couplers Features and advantages

a.Saving cost and easy operation than the lapping of rebar

b.One time loading can finish the rib peeling and thread rolling together.

c.Single step process, only one machine, one operator.

d.Assemble by visual inspection

e.Standard ISO parallel Metric Thread designs.

f.Used for many kinds of connections for a position or transition couplers

CPDL Rebar Coupler China Steel Rebar Coupler Manufacturers OEM/ODM On-demand Customized Rebar Splicing Coupler Wholesale Thread Rebar Couplers Standard Type


Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel
Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel

Company Profile

Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelChiping Dingli Steel sleeve Co., Ltd. Was founded in 2011. With more than 10 years of experience in the field of rebar couplers manufacture, the company is located in Xinfa Industrial Park, Chiping County, Liaocheng City, Shandong Province. The registered capital is 6 million.

Covers an area of 5, 000 square meters. 2011-2015 mainly in the Chinese domestic market, has served China′s major nuclear power plants and national enterprise buildings, 2016-now began to export, the establishment of 6 types of reinforced couplers, can be customized to a variety of sizes of couplers, in 2017 developed the cone thread system, in 2018 developed the fast connection system, We did not stop on the road of research and development, and strive to break through Dingli is a professional development, production and sales of rebar coupler and other mechanical connection products of the enterprise.

From inner management to outer sales, from technology improvement to customer complaints, we put all our efforts in providing products with high quality, perfect service and reasonable price that clients require. Our products have been exported to: USA, Mexico, Colombia, Australia, Poland, Russia, Korea, Thailand, India, Singapore, Malaysia, Vietnam, KSA, Qatar, Kuwait, Iran, Philippines, Ethiopia, Pakistan. Our annual productivity is 5, 000, 000 PCS of different kind of rebar coupler.

The most fast delivery time is within 5days for one container. Clients inspection on site is acceptable at anytime. We do produce Rebar parallel thread connection, cold press connection, rebar bridging connection, rebar taper thread connection, rebar nut-lock screw connection, one touch coupler and bolt coupler. We give client the best product and service with reasonable price, highest quality. Our company is approved by the industry with good faith strength and product quality.

Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel
Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler FactorysteelSteel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel

Packaging & Shipping



Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel
FAQ

Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel1. Q: Are you a trading company or manufacturer?

    A: We are an original equipment manufacturer.

2. Q: How long is your delivery time?

    A: It is according to the model and quantity.

        Generally, it is 3-5 days if the products are in stock.

        It will be 15-30 days if you want to customize the products

3. Q: What are your terms of payment?

    A: We accept T/T, Western Union, Money Gram, PayPal, Alibaba Escrow, etc.

        Payment<=USD 5000, 100% in advance.

        Payment>=USD 5000, 30% T/T in advance, balance before shipment.

 4. Q: Do you provide samples? Is it free or extra?

A: Yes, we could offer the sample for free charge, but clients do not need to pay the cost of freight.

Steel Bar Couplers Rebar Splicing System Save Cost Easy Operation Rebar Coupler Factorysteel
